Tachometer Gauge Kit for Massey Ferguson Tractors – Compatible with MF35, MF50, MF65, MF135, MF150, and MF165 Models

Description

Gauge set fits Massey Ferguson: TO20 TO30 TO35

MF 35 F40 50 65 85 88 Super 90 135 150 165 175 180

Industrials: MF20 30 2135

Temperature Gauge – 72″ Capillary, 2″ / 52mm,5/8″-18 UNF Brass Connection with 1/2″ NPT pipe bushing, Chrome Bezel , Studs & bracket with light option.

Replaces Massey numbers: 881396M91,180727M93

Oil Pressure Gauge – 2″ / 52mm, 1/8″ NPT Male thread Connection Chrome Bezel , Studs & bracket with light option.

Replaces Massey part number: 506902M92 with 75 psi gauge

Amp Gauge  – 2″ / 52mm Chrome Bezel, Studs & bracket with light option.

Replaces Massey numbers: 515521M91

Fuel Gauge – 2″ / 52mm Chrome Bezel,

Replaces Massey part numbers: 894844M1, 898418M1

Tachometer–  85mm- diameter, 5/8″ -18 UNF Thread, Clockwise Rotation,

Replaces Massey part numbers: 1674637M91

These gauges fit 2″ / 52mm diameter holes, they have chrome bezels with glass lens and are Yellow Zinc “Cad” Plated for corrosion resistance protection! They have mounting studs and brackets, rubber gasket seals for mounting flush to dash. They have a light option included so owner has option to use or not to use!

MFTMP72

MFO1/8MPTM

MFAUN30

MFTCH1674637M91

MFF894844MI
